Automann

568.1027CF - Landing Gear Set Ins-Mount 17in CushFt

568.1027CF - Landing Gear Set Ins-Mount 17in CushFt

$623.98

$623.98

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

Ref. #: A401G317, SF28TFC

Brand: Automann

Product Level: Fleet Standard

Description

Consists of: 1-568.1004, 1-568.1008, 2-568.1040, 2-M5855, 6-FSW405, 3-ENC10MM, 1-M5860, 1-568.1039, 1-568.1027CFG, 1-568.1027CFN

Applications: Jost

Unit Size: 1

Weight: 204 lbs

Pkg. Dims (in)

46 X 34 X 22

Applications	Jost
Landing Gear Type	Jost Style
Mounting Style	Inside
Shoe Type	Cushion
Side Load Capacity	32,000 Lbs
Lift Capacity	65,000 Lbs
Static Load	200,000 Lbs
Travel (E)	17.000"
Fully Retract Height (F)	33.000"
C2E Outer Leg (G)	25.000"
Handle (H)	568.1004
Crank Hanger	568.1008
Brace Lug	568.1040
Cross Shaft (K)	568.1007
Shoe	N/A
C2E (L)	N/A
Shoe LXW (M)	10" x 10"
# Holes (N)	10
C2C Top Mount Holes (O)	7.500"
C2C Side Down Holes (P)	2.250"
Cross Section (Q)	5.25" x 5.25"
Shaft Standout (R)	4.750"
